Bio-Rad Experion Electrophoresis Station

$149.00

The Experion automated electrophoresis station performs all of the steps of gel-based electrophoresis in one compact, durable unit. It automates analysis by combining electrophoresis, staining, destaining, band detection, and imaging into a single, 30 min step. It's an electrophoresis cell, power supply, and imager built into a single device and is designed for easy, precise operation:

  • Highly accurate laser provides precise fluorescence detection

  • USB port allows easy installation and maximum usability

  • Built-in power supply reduces cost and saves bench space


Specifications

Electrophoresis Station Materials Specifications



Casing

ABS and polycarbonate

Translucent lid

Polycarbonate

Latch

Polycarbonate

Rubber feet

Thermoplastic rubber

Power button

ABS and polycarbonate

Electrophoresis Station Operation Specifications



Power supply

100–240 VAC, 50/60 Hz, 31 VA

Power indicator

LED

Electrode wires

90% platinum, 10% iridium alloy, 0.5 mm diameter

Laser

Photodiode, 635 nm excitation

Detector

Photoemission, 685 nm emission

Fuse

250 V T 2A, 5 x 20 mm

Voltage limit

2,200 V (when multiple channels are printed)

Computer connection

USB 2.0 cable

Weight

4.58 kg (10.1 lb)

Dimensions (W x D x H)

15 x 31 x 29 cm (5.9 x 12.2 x 11.4")
